Mining Vibrating Screen

Share

Mining vibrating screen specializes in screening and separating stones in the quarry. It is also used in coal processing, mine processing, building materials, power and chemical industries to classify the materials.

YIINGDA linear vibrating screens fulfill all these requirements perfectly. They can handle the largest quantities of materials, and classify them to a high level of accuracy. Driven by force exciters, they are specially adapted to the widest range of requirements.


Introduction

1.It can do dewatering from ore, coal, coke, sinter, pellets or rock reliably


2. Easily Replaced variety of screen.



3.Low noise, low consumption, high efficiency and low cost.



4.High accuracy of screening, no dust pollution, environmental protection.



5. Small volume, light weight, simple structure, convenient installation, easy maintenance.










Parameter

Linear Vibrating Screen

Model

Feeding size

(mm)

Capacity

(t/h)

Voltage
  (V)

Power
  (kw)

Vibrating frequency (times/min)

Double amplitude

(mm)

Weight (kg)

1 layer

2 layers

3 layers

ZS-0.4×1.2

≤30

6

380

0.4×2

1500

2-4

160

189

218

ZS-0.5×1.2

≤30

7

0.75×2

1500

2-4

260

297

335

ZS-0.6×1.2

≤30

8

0.75×2

1500

2-4

280

317

355

ZS-0.7×1.5

≤50

12

1.5×2

1500

2-4

420

468

515

ZS-0.8×1.6

≤50

14

1.5×2

1500

2-4

457

520

554

ZS-0.9×1.8

≤50

15

2.0×2

960

2-4

870

927

984

ZS-0.9×2.4

≤60

16

2.0×2

960

2-4

1200

1298

1305

ZS-1.2×2.4

≤60

20

2.5×2

960

3-5

1500

1625

1750

ZS-1.2×3.0

≤60

24

2.5×2

960

3-5

1760

1913

2066

ZS-1.5×3.0

≤60

28

3.7×2

960

3-5

2400

2629

2858


Circular Vibrating Screen



Model

Screening area(m2)

Input particle size(mm)

Capacity

(t/h)

Motor

Single point dynamic load(KN)

Single point max dead load (KN)

Model

Power(kw)

YA1236

4.3

200

70-250

Y160M-4

11

±0.802

±4.008

2YA1236

4.3

200

70-250

Y160M-4

11

±0.802

±4.008

YA1536

5.4

400

200-650

Y160M-4

11

±0.931

±4.665

2YA1536

5.4

400

200-650

Y160L-4

15

±0.931

±4.665

YA1836

6.5

400

250-750

Y160M-4

11

±0.980

±4.900

2YA1836

6.5

400

250-750

Y160L-4

15

±0.980

±4.900

YA1842

7.6

400

300-850

Y160L-4

15

±0.928

±4.640

2YA1842

7.6

400

300-850

Y160L-4

15

±0.928

±4.640

YA1848

8.6

400

400-950

Y160L-4

15

±1.392

±6.958
